uATX - SiS662 / SiS964 - Serial ATA-150-Network adapter - Integrated - Ethernet,

Our Price:
$672.80 CAD
Special Order
Shipping Weight: 1 lbs
SKU #: (131993)
Mft. Part #: BLKD201GLY2
Add to My Bookmark
HardwareWiki.org Info

Customer Reviews
Specifications
Additional Information

DDR2 667 MHz validated to run at 533 MHz only

Chipset:

  • Northbridge: SiS SiS662
  • Southbridge: SiS SiS964


  • Back Panel Interfaces    2 x mini-DIN
    1 x DB-9 RS-232 Serial
    1 x DB-25 IEEE 1284 Parallel
    1 x HD-15 VGA
    1 x RJ-45 Network
    2 x Type A USB 2.0 USB
    1 x Mini-phone Audio Line In
    1 x Mini-phone Audio Line Out
    1 x Mini-phone Microphone
    Brand Name    Intel
    Chipset Manufacturer    SiS
    Chipset Model    SiS662
    Dimensions    17.15cm Width x 17.15cm Depth
    Expansion Slots    1 x PCI
    Fast Ethernet    Yes
    Front Panel Interfaces    1 x HDD LED
    1 x Reset Switch
    1 x On/Off Switch
    1 x Power LED
    2 x USB Header
    Front Side Bus    533MHz
    Graphics Controller Manufacturer    SiS
    Graphics Controller Model    Mirage 1
    IDE Controller    Yes
    IDE Standard    Ultra ATA/133 (ATA-7)
    Manufacturer    Intel Corporation
    Manufacturer Part Number    BLKD201GLY2
    Manufacturer Website Address    www.intel.com
    Marketing Information

    D201GLY2 Desktop Board is an innovative solution for the sub-value market segment. With an Intel Celeron processor and graphics integrated on the board, this board enables easy system integration and helps you to achieve a lower system cost. This board has 10/100 LAN, support up to six Hi-Speed USB 2.0 ports and 2 SATA (1.5 GB/s), providing both connectivity and ease of use for your computing needs such as email and Internet access, instant messaging and Voice Over IP (VoIP).

    The Intel Desktop Board D201GLY2 is built in smaller uATX-Compatible form factor providing lower power consumption and passive thermal solution.


    Maximum Memory    1GB
    Memory Standard    DDR2-667/PC2-5300
    DDR2-533/PC2-4200
    DDR2-400/PC2-3200
    Memory Technology    DDR2 SDRAM
    Number of IDE Interfaces    1
    Number of Memory Slots    1
    Number of SATA Interfaces    2
    Package Contents

  • 10 x D201GLY2 Desktop Board
  • 10 x Cable, ATA 66/100 IDE
  • 10 x Cable, Serial ATA
  • 10 x CD, Express Installer
  • 10 x Configuration Label
  • 10 x I/O Shield
  • 1 x Quick Reference Guide


  • Package Type    Bulk
    Packaged Quantity    10
    Processor Socket    Socket 478
    Processor Support    Celeron
    Product Model    D201GLY2
    Product Name    D201GLY2 Desktop Board
    Product Type    Desktop Board
    SATA Controller    Yes
    SATA Standard    Serial ATA/150
    Sound Controller Manufacturer    Analog Devices
    Sound Controller Model    AD1888
    Total Processor Support    1

    Manufacturer's Warranty Contact Information

    Intel retail box processors and motherboards have a limited warranty of 3 Years. This warranty is provided by Intel.

    Support URL: www.intel.com
    Support Phone Number: 1-(800)-628-8686

    E-Mail Intel Technical Support:
    http://supportmail.intel.com/scripts-emf/welcome.aspx?id=

    Processor Technical Support
    1-916-377-7000
    07:00-17:00 PST  Monday-Friday
