Print server - USB / parallel - EN, Fast EN, EtherTalk - 10Base-T, 100Base-TX

Our Price:
$234.43 CAD
Special Order
Shipping Weight: 1.3 lbs
SKU #: (208092)
Mft. Part #: 0173-004
Add to My Bookmark
HardwareWiki.org Info

Customer Reviews
Specifications
Additional Information
  • Power provided by external supply. Maximum 5.6W (Type PS-H, 5.1 VDC 2000mA)

    Security:

  • NetWare: Encrypted passwords,NetWare Packet Signature Level 1,2,3
  • UNIX/Linux:Root password,user access list and printer access
  • HTTPS
  • Firmware Uppgrade:

  • Firmware upgrade with AXIS ThinWizard, FTP, NetPilot or Embedded webpages
  • Supported Languages:

  • English, French, German, Italian, Spanish
  • Logical Printers:

  • Logical printer ports can be programmed to perform auto ASCII to PostScript conversion, string before and after job,string substitution, alternative output and character set conversion
  • Logical Connection:

  • Ethernet:Use of IEEE802.2,IEEE802.3,SNAP and Ethernet II frame types simultaneously
  • Fast Ethernet: Supports NWay that provides auto-detection of network speed. Use of IEEE802.2, IEEE802.3, SNAP and Ethernet II frame types simultaneously, full duplex

  • Brand Name    Axis
    Certifications & Standards

    IEEE:

  • IEEE 1284
  • IEEE802.2
  • IEEE802.3
  • Approvals:

  • EMC: EN 55022/1998, EN 55024:1998, EN 61000-3-2, EN 61000-3-3, VCCI Class B, C-TICK AS/NZS 3548, Compliance to FCC part 15 Subpart B, Class B
  • Safety: EN 60950

  • Compatibility

    Supported Printers:

  • Parallel printers from e.g. Canon, Epson, HP, Lexmark, Minolta, NEC, Oce, Ricoh, TEC and Xerox
  • USB 1.1 & 2.0 printers from e.g. Brother, Canon, Epson, HP, IBM, Kyocera, Lexmark, Minolta, NEC, OKI, TEC and Xerox
  • Supported Systems:

  • Microsoft Windows: Windows 98, Me, NT4, 2000, and XP
  • Novell NetWare: NetWare 3.12, 4.10, 4.2, 5.X, 6.0 and above
  • Microsoft LAN Manager: LAN Manager 2.0c and above, running under OS/2 ver.1.3 and above
  • IBM LAN Server:LAN Server 1.3 and above, running under OS/2 v1.3 and above including OS/2 Warp,OS/2 Warp Connect
  • All computers supporting the TCP/IP suite of protocols including:
    • BSD systems: BSD 4.2, 4.3,4.4, SunOS4 (SOLARIS 1.x), DEC Ultrix etc
    • System V systems:R3,R4,AT&T.Interactive, SCO,SUNOS5 (Solaris 2.x), HP-UX, Silicon Graphics IRIX,DEC Alpha OSF/1,IBM AIX, BULL (BOS,AIX), Linux
    • Other systems: IBM (MVS,VM,VSE,OS/400), DEC VMS, guidelines for other systems
  • Apple EtherTalk: Macintoshes System 7, PowerMac, PowerMac G3/G4, MacOS X version 10.X
  • WWW:Netscape 4.76 or higher and MS Internet Explorer 4.x or higher

  • Connectivity Media    Category 5 Twisted Pair 10/100Base-TX
    Controls    Test Button
    Data Transfer Rate    10Mbps Ethernet
    100Mbps Fast Ethernet
    10Mbps
    100Mbps
    Dimensions    2.9cm Height x 6.2cm Width x 11.7cm Depth
    Form Factor    Wall-mountable
    Input Current    2000 mA
    Input Voltage    5.1 V DC
    Interface Type    10/100Base-TX
    Interfaces/Ports    1 x RJ-45 10/100Base-TX Network Auto-negotiating
    1 x 36-pin Centronics Parallel Printer
    1 x USB Printer
    Management
  • AXIS ThinWizard for installation, configuration, monitoring and firmware upgrading
  • Embedded web pages for product configuration, management and monitoring
  • SNMP-MIB II compliant (over UDP/IP and IPX), private enterprise MIB included
  • AXIS NetPilot for installation and configuration in NetWare 3.12 and Bindery mode
  • Print server/job/printer status presentation and management via NWAdmin/PCONSOLE

  • Manufacturer    Axis Communications
    Manufacturer Part Number    0173-004
    Manufacturer Website Address    www.axis.com
    Marketing Information

    Offering the connectivity for sharing the very latest USB & parallel printers over the network, the AXIS 5550 is the ideal dual-port solution for printing in large organizations and enterprise networks. Compatible with virtually all networking environments, the AXIS 5550 offers multiprotocol support for printing directly from almost any application. The web based interface is multilingual and supports HTTPS for secure print server management.


    Memory    8MB RAM
    Memory Details    8MB RAM
    2MB Flash Memory
    Package Contents
  • AXIS 5550 Network Print Server
  • AXIS Network Product CD
  • Wall mounting clip
  • USB cable

  • Power Consumption    5.6 W Maximum
    Processor    100MHz 32-bit RISC
    Product Name    5550 Network Print Server
    Product Type    Print Server
    Protocols    NetBEUI
    TCP/IP
    LPR
    IPP
    WINS
    ARP
    DHCP
    DNS
    DDNS
    SNMP
    SLP
    SAP
    UDP
    NCP
    NDS
    RIP
    OSPF
    NLSP
    LIP
    BootP
    RARP
    Telnet
    TFTP
    FTP
    PROS
    HTTP
    SSL
    TLS
    ICMP
    IGMP
    EtherTalk
    AAPR
    ATP
    DDP
    NBP
    PAP
    RTMP
    Zip
    Standard Warranty    1 Year Limited
    Status Indicators
  • Power
  • Network

  • Temperature    5 ?C to 40 ?C
    Weight    0.08 kg
