Home > Categories > Mainboard - Other Chipset > INTEL > Product (261509)

MOTHER BD UATX PCI PS2 USB RJ 897042

Our Price:
$769.34 CAD
Special Order
Shipping Weight: 1 lbs
SKU #: (261509)
Mft. Part #: BLKDG31GL
Add to My Bookmark
HardwareWiki.org Info

Customer Reviews
Specifications
64-bit Processing    Yes
Additional Information

Chipsets:

  • Northbridge: Intel G31 Express
  • Southbridge: Intel ICH7
  • BIOS Features:

  • BIOS (resident in the SPI Flash device)
  • Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,and SMBIOS
  • Instantly Available PC Technology:

  • Support for PCI Local Bus Specification Revision 2.3
  • Suspend to RAM support
  • Wake on PCI, RS-232, front panel, PS/2 devices, USB ports, and LAN
  • Hardware Monitoring:

  • Voltage sense to detect out of range power supply voltages
  • Thermal sense to detect out of range thermal values
  • Two fan headers
  • Two fan sense inputs used to monitor fan activity
  • Power Management:

  • Software support through Advanced Configuration and Power Interface (ACPI)
  • Hardware Support:
    • Power connector
    • Fan headers
    • LAN wake capabilities
    • Instantly Available PC technology
    • Wake from USB
    • Power Management Event signal (PME#) wake-up support
    • +5V standby power indicator LED


    Audio Channels    3.1
    Back Panel Interfaces    2 x mini-DIN
    1 x HD-15 VGA
    4 x Type A USB 2.0 USB
    1 x RJ-45 Network
    1 x Mini-phone Audio Line In
    1 x Mini-phone Audio Line Out
    1 x Mini-phone Microphone
    Brand Name    Intel
    Chipset Manufacturer    Intel
    Chipset Model    G31 Express
    Dimensions    21.84cm Width x 24.38cm Depth
    Expansion Slots    2 x PCI
    Fast Ethernet    Yes
    Floppy Controller    Yes
    Form Factor
    Front Panel Interfaces    1 x HDD LED
    1 x Reset Switch
    1 x On/Off Switch
    1 x Power LED
    1 x Audio Header
    2 x USB Header
    1 x Speaker
    1 x S/PDIF
    1 x COM1
    Front Side Bus    1333MHz
    1066MHz
    800MHz
    Graphics Controller Manufacturer    Intel
    Graphics Controller Model    Graphics Media Accelerator 3100
    IDE Controller    Yes
    IDE Standard    Ultra ATA/100 (ATA-6)
    Manufacturer    Intel Corporation
    Manufacturer Part Number    BLKDG31GL
    Manufacturer Website Address    www.intel.com
    Marketing Information

    DG31GL Desktop Board offers a cost-efficient integrated graphics solution for the budget conscious user. DG31GL Desktop Board is built with affordability and flexibility in mind, and supports Intel Core 2 Quad processors, Intel Core 2 Duo processors, Intel Pentium Dual-Core processors and Intel Celeron processors with 1333/1066/800 MHz system bus in the LGA775 package. Other features include dual-channel DDR2 800/667 MHz SDRAM, Intel Graphics Media Accelerator 3100 (Intel GMA 3100), integrated 10/100 Network Connection, Intel High Definition Audio (4 channel audio) and up to eight USB 2.0 ports.


    Maximum Memory    4GB
    Memory Standard    DDR2-800/PC2-6400
    DDR2-667/PC2-5300
    Memory Technology    DDR2 SDRAM
    Number of IDE Interfaces    1
    Number of Memory Slots    2
    Number of SATA Interfaces    2
    Package Type    Bulk
    Processor Socket    Socket T
    Processor Support    Core 2 Quad
    Core 2 Duo
    Pentium Dual-Core
    Celeron
    Product Model    DG31GL
    Product Name    Essential DG31GL Desktop Board
    Product Series    Essential
    Product Type    Desktop Board
    SATA Controller    Yes
    SATA Standard    Serial ATA/300
    Sound Controller Manufacturer    Realtek
    Sound Controller Model    ALC268-GR
    Total Processor Support    1

    Manufacturer's Warranty Contact Information

    Intel retail box processors and motherboards have a limited warranty of 3 Years. This warranty is provided by Intel.

    Support URL: www.intel.com
    Support Phone Number: 1-(800)-628-8686

    E-Mail Intel Technical Support:
    http://supportmail.intel.com/scripts-emf/welcome.aspx?id=

    Processor Technical Support
    1-916-377-7000
    07:00-17:00 PST  Monday-Friday
